EXITEDGE-1SNY/E

Spec Sheet Instructions Spec Sheet

EXITEDGE-1SNY/E

NYC-approved single-face edge-lit exit sign

Clear, white or mirrored acrylic panel by model (see Panel Color in specs); red letters

Aluminum housing in white or brushed aluminum finish

AC-only and 90-minute battery backup models available

Self-diagnostic models available

View Technical Specs

View Price & Availability

Dimensions

Weight: 1.0 lbs

Technical Specifications

Performance

Product Type

Emergency Unit

Description

Emergency Thermoplastic Unit with Round Heads

Input Power (W)

Lumens

160lm

Electrical

Power Factor

0.4

Input Voltage

120-277V

Operating Frequency

50/60Hz

Input Current @ 120V (mA)

25mA

Input Current @ 277V (mA)

15mA

Maximum Output Current (Amps)

1,000mA

Maximum Output Wattage

Dual Voltage Circuit Operation

Operating Temperature

32°F to 104°F (0°C to 40°C)

Battery Type

Nickel-Metal Hydride

Storage Temperature

68°F to 86°F (20°C to 30°C)

Storage Shelf Life

3 years before the initial charge. 5 years after initial charge.

Self Diagnostics

No, manual test only

Remote Test Switch

Emergency Characteristics

Emergency Illumination

90 minutes

Battery Backup

Yes

Battery Voltage

3.6V

Recharge Time Required

24-hours

Battery Operating Temperature

0°F to 40°F (32°C to 104°C)

Installation

Mounting Method

Back

Mounting Type

Wall

Maximum Mounting Height (ft.)

20 ft

Spacing Criteria for Emergency Egress

14 ft on center assuming 7.5 ft mounting height with egress path 3 ft out

Cold Weather Rated

Construction

Shape

Rectangle

Housing Material

Thermoplastic

Housing Color

White

Remote Capacity

No. of Heads

2-Lamp Heads

Head Shape

Round

Remote Head Lumens (lm)

160lm

Remote Heads Replaceable

Compliance

Listings

UL924 Listed

Environment

Suitable for use in dry and damp environments

IP Rating

IP20

T20 Compliant

Can be used to conform with the requirements of California Title 20

California Title 24 JA8 Compliant

California Energy Commission (CEC) Status

Lawful for Sales in California

FCC

Complies with Part 15 of the FCC Rules

Other

Compatible Products

EREMOTE-RTS
Wall Mount Remote Test Button Switch

5-Year, No-Compromise Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
