• High-output, high performance industrial high bay
  • High ambient temperature rating of 55°C
  • Diffusion lens reduces glare
  • Multiple mounting options: pendant, surface or chain
  • 100,000-Hour LED lifespan
  • 5-Year, No-Compromise Fixture Warranty and 10-Year, No-Compromise Lightcloud Warranty
  • Built in support Lightcloud™
  • Easy setup - simply power on, confirm device connectivity and call 844-LIGHTCLOUD
View Technical Specs
Performance
Watts 80W
Color Temp 3000K (Warm)
Lumens 5,966 lm
Efficacy 71.4 lm/W
Color Accuracy 81 CRI
L70 Lifespan 100,000 Hours
Type Constant Current
120V 0.68A
208V 0.42A
240V 0.36A
277V 0.30A
Input Watts 83.6W
Dimensions
Link to Dimension Drawing

Weight: 24.1 lbs

Technical Specifications

Installed with Lightcloud

Lightcloud is a commercial wireless lighting control system fully developed and supported by RAB. It's powerful and flexible, yet easy to use and install.

Learn More
Lightcloud
Lightcloud Sensor Installed
Occupancy, vacancy, and closed-loop daylight harvesting in one versatile sensor. Control any fixture in your Lightcloud system. Learn more at www.lightcloud.com *Optimal detection performance rated for up to 45 ft
Compliance
UL Listed
Suitable for wet locations
Optical
Optics
120° downlight
Construction
Cold Weather Starting
The minimum starting temperature is -40°F (-40°C)
Electrical
Driver
Constant Current, Class 2, 100-277VAC, 50-60Hz, 120V: 0.68A, 208V: 0.42A, 240V: 0.36A, 277V: 0.30A, 4kV surge protection
THD
4.9% at 120V, 9.5% at 277V
Power Factor
99.6% at 120V, 95.1% at 277V
