FWAFER6

Tested to UL 263 standards for 2-hour fire resistance

5 color temperatures in 1 SKU (2700K, 3000K, 3500K, 4000K, 5000K)

Super slim, edge-lit fixture

No recessed housing or J-box required

New construction or retrofit applications

View Technical Specs

View Price & Availability

Performance

Watts	15W
Color Temp	2700/3000/3500/4000/5000K
Lumens	1,330 lm
Efficacy	89
Color Accuracy	>90 CRI
L70 Lifespan	50,000 Hours

Type	Constant Current, Class 2
120V	0.14A
208V
240V
277V
Input Watts	15W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 1.4 lbs

Technical Specifications

Performance

Product Type

Edge-Lit Wafer

Description

Fire-resistant edge-lit wafer offered in 4" and 6" models with 5 selectable color temperatures in one wafer. The remote driver makes these ideal for new construction and retrofit applications.

Wattage Equivalency

75W Halogen

Input Wattage

15W

Lumens

2700K @ 1,270lm; 3000K @ 1,313lm; 3500K @ 1,364lm; 4000K 1,378lm; 5000K 1,327lm

Efficacy

2700K @ 85lm/W; 3000K @ 88lm/W; 3500K @ 91lm/W; 4000K @ 92lm/W; 5000K @ 88lm/W

L70 Lifespan

50,000-Hour LED lifespan based on IES LM-70 results

Electrical

Driver

Constant Current, Class 2, 60 Hz, 120V, 120V: 0.14A

THD

≤20%

Power Factor

≥0.9

Dimmable

Yes, using compatible TRIAC/ELV dimming systems. Dimmable down to 10%.

Input Voltage

120V

Operating Frequency

60 Hz

Input Current @ 120V (mA)

137mA

Operating Temperature

-4°F to 104°F (-20°C to 40°C)

Flicker

LED Characteristics

Color Temperature

Field adjustable via dip switch 2700/3000/3500/4000/5000K

Color Accuracy (CRI)

>90 CRI

R9 Value

High color performance with R9 greater than or equal to 50

Color Consistency

4-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color

Color Stability

LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period

Color Uniformity

RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

Beam Angle

90°

Installation

Mounting

Recessed Housing

Installation

Can be installed in ceilings from 3/8" to 5/8" thick with spring-loaded retention clips. Cutout template included in box. Can be removed from below the ceiling for service or replacement.

Remote Driver/Junction Box

Die formed metal driver / junction box with captive hinged junction box cover. Recessed CCT Selectable dipswitch. Listed for (6) #12 AWG 90°C splice conductors, 2-in, 2-out plus (2) ground. (4) 1/2" conduit pry-outs. (3) quick snap-in connectors for quick and reliable line voltage connections. Integral mounting facilitates direct mounting to building structure or mounting frame.

Construction

Size

Shape

Round

Finish

White+Red

Enclosure Material

Metal

Trim Style

Smooth

Lens

Polycarbonate light diffuser distributes light evenly and smoothly for general lighting applications

Cut Out Template Size

5 7/8"

IC Rated

Suitable for direct contact with insulation

Air Tight

Housing certified Air Tight as per ASTM E283

Compliance

Fire Resistant

Tested to UL 263 standards for 2-hour fire resistance

Environment

Suitable for indoor and outdoor use in dry, damp, and wet environments

Energy Star Approved

This product is ENERGY STAR® Version 2.2 Certified.

DLC Listed

Not applicable

Certification Model Number

DLW0097(FWAFER6)

T20 Compliant

Not applicable

California Title 24 JA8 Compliant

Can be used to conform with the requirements of California Title 24 Part 6

California Energy Commission (CEC) Status

Lawful for Sales in California

RoHS

Mercury and UV free. RoHS-compliant components.

FCC

Complies with Part 15B of the FCC Rules

Trade Agreements Act Compliant

This product is a product of Cambodia and a "designated country" end product that complies with the Trade Agreements Act

Other

Accessories

EXTCBL-FA-6
6' Extension Cable
EXTCBL-FA-12
12' Extension Cable
EXTCBL-FA-20
20' Extension Cable
DRI-EMB-15S-LV
2-n-1 Driver + Battery Backup

5-Year, No-Compromise Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
