FWAFER6B
FWAFER6B
- Tested to UL 263 standards for 2-hour fire resistance
- 5 color temperatures in 1 SKU (2700K, 3000K, 3500K, 4000K, 5000K)
- Super slim, edge-lit fixture
- No recessed housing or J-box required
- New construction or retrofit applications
Performance
| Watts | 15W |
| Color Temp | 2700/3000/3500/4000/5000K |
| Lumens | 1,330 lm |
| Efficacy | 89 |
| Color Accuracy | >90 CRI |
| L70 Lifespan | 50,000 Hours |
| Type | Constant Current, Class 2 |
| 120V | 0.14A |
| 208V | |
| 240V | |
| 277V | |
| Input Watts | 15W |
Dimensions
Weight: 1.4 lbs
Technical Specifications
Performance
Product Type
Edge-Lit Wafer
Description
Fire-resistant edge-lit wafer offered in 4" and 6" models with 5 selectable color temperatures in one wafer. The remote driver makes these ideal for new construction and retrofit applications.
Wattage Equivalency
75W Halogen
Input Wattage
15W
Lumens
2700K @ 1,272lm; 3000K @ 1,311lm; 3500K @ 1,358lm; 4000K 1,366lm; 5000K 1,306lm
Efficacy
2700K @ 85lm/W; 3000K @ 87lm/W; 3500K @ 91lm/W; 4000K @ 91lm/W; 5000K @ 87lm/W
L70 Lifespan
50,000-Hour LED lifespan based on IES LM-70 results
Electrical
Driver
Constant Current, Class 2, 60 Hz, 120V, 120V: 0.14A
THD
≤20%
Power Factor
≥0.9
Dimmable
Yes, using compatible TRIAC/ELV dimming systems. Dimmable down to 10%.
Input Voltage
120V
Operating Frequency
60 Hz
Input Current @ 120V (mA)
137mA
Operating Temperature
-4°F to 104°F (-20°C to 40°C)
Flicker
5%
LED Characteristics
Color Temperature
Field adjustable via dip switch 2700/3000/3500/4000/5000K
Color Accuracy (CRI)
>90 CRI
R9 Value
High color performance with R9 greater than or equal to 50
Color Consistency
4-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color
Color Stability
LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period
Color Uniformity
RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.
Beam Angle
90°
Installation
Mounting
Recessed Housing
Installation
Can be installed in ceilings from 3/8" to 5/8" thick with spring-loaded retention clips. Cutout template included in box. Can be removed from below the ceiling for service or replacement.
Remote Driver/Junction Box
Die formed metal driver / junction box with captive hinged junction box cover. Recessed CCT Selectable dipswitch. Listed for (6) #12 AWG 90°C splice conductors, 2-in, 2-out plus (2) ground. (4) 1/2" conduit pry-outs. (3) quick snap-in connectors for quick and reliable line voltage connections. Integral mounting facilitates direct mounting to building structure or mounting frame.
Construction
Size
6"
Shape
Round
Finish
White+Red
Enclosure Material
Metal
Trim Style
Baffle
Lens
Polycarbonate light diffuser distributes light evenly and smoothly for general lighting applications
Cut Out Template Size
5 7/8"
IC Rated
Suitable for direct contact with insulation
Air Tight
Housing certified Air Tight as per ASTM E283
Compliance
Fire Resistant
Tested to UL 263 standards for 2-hour fire resistance
Environment
Suitable for indoor and outdoor use in dry, damp, and wet environments
Energy Star Approved
This product is ENERGY STAR® Version 2.2 Certified.
DLC Listed
Not applicable
Certification Model Number
DLW0099(FWAFER6B)
T20 Compliant
Not applicable
California Title 24 JA8 Compliant
Can be used to conform with the requirements of California Title 24 Part 6
California Energy Commission (CEC) Status
Lawful for Sales in California
RoHS
Mercury and UV free. RoHS-compliant components.
FCC
Complies with Part 15B of the FCC Rules
Trade Agreements Act Compliant
This product is a product of Cambodia and a "designated country" end product that complies with the Trade Agreements Act
Other
Accessories
EXTCBL-FA-6
6' Extension Cable
EXTCBL-FA-12
12' Extension Cable
EXTCBL-FA-20
20' Extension Cable
DRI-EMB-15S-LV
2-n-1 Driver + Battery Backup
6' Extension Cable
EXTCBL-FA-12
12' Extension Cable
EXTCBL-FA-20
20' Extension Cable
DRI-EMB-15S-LV
2-n-1 Driver + Battery Backup
Warranty
RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
