• Energy-efficient, maintenance-free LED wrap fixture
  • Multiple mounting options: surface, pendant or chain
  • High-reflectance white finish for optimal output
  • Diffusion wrap-around lens for smooth light distribution
  • 0-10V dimming, standard
  • 100,000-Hour LED lifespan
View Technical Specs
Performance
Watts 50W
Color Temp 3500K (Warm Neutral)
Lumens 6,225 lm
Efficacy 133.9 lm/W
Color Accuracy 83 CRI
L70 Lifespan 100,000 Hours
Type Constant Current
120V 0.38A
208V 0.26A
240V 0.23A
277V 0.17A
Input Watts 46.5W
Dimensions
Link to Dimension Drawing

Weight: 17.9 lbs

Technical Specifications
Compliance
UL Listed
Suitable for damp locations
DLC Listed
This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: PCHA7SBR
Performance
Lifespan
100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations
Wattage Equivalency
Equivalent to (3) F32T8
LED Characteristics
Color Stability
LED Color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period
Color Uniformity
RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.
Electrical
Driver
Constant current, Class 2, 120-277V, 50/60 Hz, 120V: 0.38A, 208V: 0.26A, 240V: 0.23A, 277V: 0.17A, 2kV surge protection
Dimming Driver
Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.
THD
3.48% at 120V, 5.25% at 277V
Power Factor
99.7% at 120V, 96.6% at 277V
Minimum Starting Temperature
0° to 40°C
Battery Backup
Battery backup will operate the fixture for 90 minutes if power fails. Wired for 120-277V.
Battery Backup Light Loss Factor
0.23
Construction
Housing
Die-formed 22 gauge, cold-rolled, post-painted steel. Post painting improves durability of the finish and eliminates the sharp edges making handling and installation safer.
Lens
Acrylic lens with diffusion for enhanced optical performance
Reflector
Aluminum with high-reflectance (91%) powder coat applied post production for a more durable finish
Finish
Formulated for high durability and long-lasting color
Green Technology
Mercury and UV free. RoHS-compliant components.
Installation
Mounting
Surface mount. Can be mounted with chains or v-hooks by others.
Other
5-Year, No-Compromise Warranty
RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
