Performance
Watts 25W
Color Temp 2700K (Residential Warm)
Lumens 1,788 lm
Efficacy 69 lm/W
Color Accuracy 93 CRI
L70 Lifespan 50,000 Hours
Type Constant Current
120V 0.22A
208V 0.13A
240V 0.11A
277V 0.1A
Input Watts 25.9W
Dimensions
Link to Dimension Drawing

Weight: 4.3 lbs

Technical Specifications

Installed with Lightcloud

Lightcloud is a commercial wireless lighting control system fully developed and supported by RAB. It's powerful and flexible, yet easy to use and install.

Learn More
Lightcloud
Lightcloud Controller Installed
LCLC/W
Fixture, Zone, and plug-load control from one powerful device. Capable of switching, 0-10V dimming, power monitoring. Can also be used to extend the range of the Lightcloud mesh network. Attach to fixture, junction box, or electrical panel. Learn more about Lightcloud.
Compliance
UL Listed
Suitable for damp locations. Recommended for indoor use only.
ADA Compliant
Meets ADA Requirements for wall-mounted luminaires.
IESNA LM-79 & LM-80 Testing
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
Performance
Lifespan
50,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations
Wattage Equivalency
Equivalent to 100W Incandescent
LED Characteristics
LEDs
Long-life, high-efficacy, surface-mount LEDs; binned and mixed for uniform light output and color
Color Stability
LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period
Color Uniformity
RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.
Electrical
Driver
Constant Current, Class 2, 120-277VAC, 50/60Hz, 350mA or 640mA
Dimming Driver
0 - 10V (at 120-277V), TRIAC and ELV (at 120V only)
THD
12.6% at 120V, 16.1% at 277V
Power Factor
98.4% at 120V, 94.3% at 277V
Battery Backup Light Loss Factor
0.18
Construction
Housing
Die-cast and extruded aluminum
Mounting
Wall mount with junction box included
Lens
Frosted polycarbonate
Operating Temperature
-20°C (-4°F) to 40°C (104°F)
Green Technology
Mercury and UV free. RoHS-compliant components.
Finish
Textured White using our environmentally friendly polyester powder coatings are formulated for high-durability and long-lasting color
Other
Warranty
RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
Buy American Act Compliance
RAB values USA manufacturing! Upon request, RAB may be able to manufacture this product to be compliant with the Buy American Act (BAA). Please contact customer service to request a quote for the product to be made BAA compliant.

Recently Viewed Products

 This is a link to the product HALVS18L927-F-W/LC HALVS18L927-F-W/LC
Architectural 1788 Lumens Halvs Forward & Up/Down Light 25W 90Cri 2700K Frosted Lens White Finish Lightcloud Controller
 This is a link to the product MCAP3B MCAP3B
Landscape Mighty Cap 3 Inches Fits 2 7/8 Inches Od Pipe Black
 This is a link to the product RDDLED2R-10D-WYY-B-STL RDDLED2R-10D-WYY-B-STL
Recessed Downlights 652 Lumens Rddled 2 Inches Round 10W Dimmable Wall Wash 2700K 80Cri Black Trim Cone Silver Trim Ring Trimless
 This is a link to the product GN4LED13YAC11R GN4LED13YAC11R
