Technical Specifications
Compliance
UL Listed
Suitable for wet locations in a covered ceiling
Construction
IC Rated
Suitable for direct contact with insulation
Aperture Size
3" Rough-In
Trim
Accepts cones with trim
Cold Weather Starting
The minimum starting temperature is -40°C (-40°F)
Maximum Ambient Temperature
Suitable for use in up to 40°C (104°F)
Housing
Cold-rolled steel and aluminum
Installation
Nailer bar and butterfly brackets included; C-channels optional for acoustic tiles
Green Technology
Mercury and UV free. RoHS-compliant components.
Performance
Lifespan
100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations
Electrical
Driver
Constant Current, Class 2, 120-277V, 50/60Hz, 120V: 0.12A, 208V: 0.08A, 240V: 0.07A, 277V: 0.06A
Performance Table*
The performance table below shows photometric data for this rough-in with the following trim modules:
NDTRIM 80° white: 1112lm, 75lm/W
NDTRIM 50° white: 1150lm, 78lm/W
NDTRIM 40° adjustable white: 1221lm, 83lm/W
NDTRIM 20° adjustable white: 1202lm, 82lm/W
NDTRIM Wall Wash white: 764lm, 52lm/W
NDTRIM 80° matte silver: 1118lm, 76lm/W
NDTRIM 50° matte silver: 1159lm, 79lm/W
NDTRIM 40° adjustable matte silver: 1263lm, 85lm/W
NDTRIM 20° adjustable matte silver: 1244lm, 84lm/W
NDTRIM Wall Wash matte silver: 805lm, 55lm/W
NDTRIM 80° black: 859lm, 58lm/W
NDTRIM 50° black: 1039lm, 70lm/W
NDTRIM 40° adjustable black: 1169lm, 79lm/W
NDTRIM 20° adjustable black: 1170lm, 79lm/W
NDTRIM Wall Wash black: 523lm, 36lm/W
LED Characteristics
Color Consistency
2-step u'-v' Circle Tolerance, previously referred to as 2-step MacAdam Ellipse, achieves consistent fixture-to-fixture color (ANSI standard C78.377.2015)
Optical
Optics
High-efficiency TIR optics. Available as a downlight (80° or 50° beam), adjustable (40° or 20° beam with 40° vertical adjustment and 360° rotation), or a wall washer.
Other
Special Order
Available in battery backup option by special request. Contact RAB customer service to order.
Buy American Act Compliance
RAB values USA manufacturing! Upon request, RAB may be able to manufacture this product to be compliant with the Buy American Act (BAA). Please contact customer service to request a quote for the product to be made BAA compliant.
