SHARK4-50W/D10/6C

Spec Sheet IES File LM79 Instructions Spec Sheet EZ Layout

SHARK4-50W/D10/6C

Impact-resistant linear washdown

Ideal for tunnels and stairwells

Mounting options: Chain, junction box, angled surface mount or vandal-resistant surface mount

IP66 Rating protects against dust & water ingress

5-Year, No-Compromise Warranty

100,000-Hour LED lifespan

View Technical Specs

View Price & Availability

Performance

Watts	50W
Color Temp
Lumens	6,862 lm
Efficacy	142.4 lm/W
Color Accuracy
L70 Lifespan

Type	Constant Current
120V	0.40A
208V	0.24A
240V	0.21A
277V	0.18A
Input Watts	48.2W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 12.2 lbs

Technical Specifications

Compliance

UL Listed

Suitable for wet locations

UL 94

5VA flame classification

NSF

NSF Certified by Public Health and Safety

IP Rating

Ingress protection rating of IP66 for dust and water

NEMA Rating

NEMA 4X rating indicates an enclosure protects against windblown dust and rain, splashing and hose-directed water, and offers additional corrosion resistance.

DLC Listed

This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: PX5J44RX (Stairwell and Passageway Luminaires)
DLC Product Code: PA687GU4 (Low-Bay Luminaires for Commercial and Industrial Buildings)
DLC Product Code: P6ZKBVP8 (Direct Linear Ambient Luminaires)

Construction

Length

4 ft

Reflector

Specular polycarbonate

Electrical

Driver

Constant Current, Class 2, 120-277V, 50/60 Hz, 120V: 0.40A, 208V: 0.24A, 240V: 0.21A, 277V: 0.18A

THD

3.58% at 120V, 10.7% at 277V

Power Factor

99.7% at 120V, 95% at 277V
