SLIMFC37W/PC2

Spec Sheet Instructions Spec Sheet

SLIMFC37W/PC2

Covers footprint of most traditional wall packs

Easy installation with hinged access, bubble level and multiple conduit entries

Tight-lock gasket keeps elements out

100,000-hour LED lifespan

5-Year, No-Compromise Warranty

View Technical Specs

View Price & Availability

Performance

Watts	37W
Color Temp	5000K (Cool)
Lumens	4,512 lm
Efficacy	139.3
Color Accuracy	74 CRI
L70 Lifespan	100,000 Hours

Type	Constant Current
120V
208V	0.20A
240V	0.17A
277V	0.15A
Input Watts	32.4W

Dimensions

Weight: 7.5 lbs

Technical Specifications

Compliance

UL Listed

Suitable for Wet Locations. Wall Mount Only.

IP Rating

Ingress protection rating of IP66 for dust and water

IESNA LM-79 & LM-80 Testing

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

Construction

Footprint

Designed to replace RAB HID WP1 wall packs, both in size and footprint template, so upgrading to LED is easy and seamless

Cold Weather Starting

The minimum starting temperature is -40°C (-40°F)

Maximum Ambient Temperature

Suitable for use in up to 40°C (104°F)

Housing

Precision die-cast aluminum housing and door frame

Full Cutoff

Allows for conformance to the IDA's fully shielding requirement, emitting no light above 90 degrees.

Lens

Microprismatic diffusion glass lens reduces glare and has smooth and even light distribution

Reflector

Specular thermoplastic

Gaskets

The unique design of the tight-lock gasket ensures no water or environmental elements will ever get inside the SLIM

Finish

Formulated for high durability and long-lasting color

Green Technology

Mercury and UV free. RoHS-compliant components.

LED Characteristics

LED

Long-life, high-efficiency, micro-power, surface mount LEDs; binned and mixed for uniform light output and color

Color Stability

LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period

Color Consistency

7-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color

Electrical

Driver

Constant Current, Class 2, 208-277V, 50-60Hz, 208V: 0.17A, 240V: 0.17A, 277V: 0.15A

Dimming Driver

Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.

THD

2.84% at 120V, 4.91% at 277V

Power Factor

99.7% at 120V, 94% at 277V

Performance

Lifespan

100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations

Installation

Mounting

Die-cast back box with four (4) conduit entry points and knockout pattern for junction box or direct wall mounting. Hinged housing and bubble level for easy installation.

Recommended Mounting Height

Up to 20 ft

Other

Accessories

Available accessories include polyshield and wire guard. Click here to see all accessories.

Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.

HID Replacement Range

Replaces 200W Metal Halide

Optical

BUG Rating

B1 U0 G0
