SWISHFA-EDGE2X4-835U/LCS

Spec Sheet IES File LM79 Instructions Master Specification Features Sell Sheet Family Spec Sheet Spec Sheet EZ Layout

SWISHFA-EDGE2X4-835U/LCS

39W 3500K (Warm Neutral)

Contemporary LED centerbasket with direct/indirect illumination

Field-adjustable light output (3 discrete steps) - can be changed before, during or after installation

100,000-Hour LED lifespan

View Technical Specs

View Price & Availability

Performance

Watts	39W
Color Temp	3500K (Warm Neutral)
Lumens	4,970 lm
Efficacy	125.8 lm/W
Color Accuracy	82 CRI
L70 Lifespan	100,000 Hours

Type	Constant Current
120V	0.33A
208V	0.19A
240V	0.17A
277V	0.15A
Input Watts	39.5W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 21.0 lbs

Technical Specifications

Installed with Lightcloud

Lightcloud is a commercial wireless lighting control system fully developed and supported by RAB. It's powerful and flexible, yet easy to use and install.

Learn More

Lightcloud

Lightcloud Sensor Installed

Occupancy, vacancy, and closed-loop daylight harvesting in one versatile sensor. Control any fixture in your Lightcloud system. Learn more about Lightcloud.

Compliance

UL Listed

Suitable for dry and damp locations.

DLC Listed

This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: PEQCR2G8

Electrical

Dimming Driver

Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.

THD

8.66% at 120V, 9.95% at 277V

Power Factor

99.3% at 120V, 96% at 277V

Surge Protection

2kV

Construction

Operating Temperature

-20°C (-4°F) to 40°C (104°F)

IC Rated

Suitable for direct contact with insulation

Housing

Sheet metal and extruded aluminum

Mounting

Recessed into T-grid ceiling. Surface and recessed mounting kits available for drywall ceilings.

Reflector

Aluminum with high reflectance white finish, optimized for uniform distribution.

Lens

Frosted polystyrene

Finish

Formulated for high durability and long-lasting color

Green Technology

Mercury and UV free. RoHS-compliant components.

LED Characteristics

LEDs

Long-life, high-efficacy, discrete, surface-mount LEDs

Color Stability

LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period

Color Uniformity

RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

Performance

Lifespan

100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations

Other

Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.

Buy American Act Compliance

RAB values USA manufacturing! Upon request, RAB may be able to manufacture this product to be compliant with the Buy American Act (BAA). Please contact customer service to request a quote for the product to be made BAA compliant.
