T8-12-48G-8CCT-HYB

Spec Sheet IES File Dimmer Compatibility List Ballast Compatibility List LM79 Instructions Sell Sheet Family Spec Sheet Spec Sheet EZ Layout

T8-12-48G-8CCT-HYB

5 Color temperature selectable between 3000K, 3500K, 4000K, 5000K, 6500K

Direct Replacement for Fluorescent Lamps: F32T8/32W, F32T8/30W, F32T8/28W, F32T8/25W

TYPE A - Plug and play compatible with most common commercial instant start T8 electronic ballasts

TYPE B - can be wired directly to line voltage 120-277V. Can be wired using Single or Double ended method

Works with both shunted and non-shunted sockets

View Technical Specs

View Price & Availability

Performance

Watts	12W
Color Temp	3000K/3500K/4000K/5000K/6500K
Lumens	1,563-1,629 lm
Efficacy	138-144 lm/W
Color Accuracy	80 CRI
L70 Lifespan	50,000 Hours

Type	Constant Current
120V	0.11A
208V	0.06A
240V	0.06A
277V	0.05A
Input Watts	12W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 0.4 lbs

Technical Specifications

Performance

Product Type

Linear Tube

Description

Hybrid Type A/B tubes allow installation on the ballast or direct wiring to line voltage. Now available with adjustable 5CCT switch.

Wattage Equivalency

32W Fluorescent

Input Wattage

12W

Lumens

1,600lm @ 3000K; 1,647lm @ 3500K; 1,133lm @ 4000K; 1,679lm @ 5000K; 1,610lm @ 6500K

Efficacy

141lm/W @ 3000K; 146lm/W @ 3500K; 147lm/W @ 4000K; 148lm/W @ 5000K; 142lm/W @ 6000K

L70 Lifespan

50,000-Hour LED lifespan based on IES LM-70 results

Electrical

THD

≤25%

Power Factor

>0.9

Dimmable

Type B @ 120V only, 0-10V & Phase cut

Input Voltage

Type A: Ballast dependent
Type B: 120-277V

Operating Frequency

50/60Hz

Input Current @ 120V (mA)

Type B: 105mA

Input Current @ 208V (mA)

Type B: 61mA

Input Current @ 240V (mA)

Type B: 55mA

Input Current @ 277V (mA)

Type B: 48mA

Operating Temperature

-4°F to 113°F (-20°C to 45°C)

Flicker

<40%

LED Characteristics

Beam Angle

160°

Color Temperature

Field adjustable via dip switch 3000K/3500K/4000K/5000K/6500K

Color Accuracy (CRI)

>80 CRI

R9 Value

High color performance with R9 greater than 0

Color Consistency

<6-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color

Color Stability

LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period

Color Uniformity

RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

Installation

Installation Method

UL Type A+B, Hybrid

Construction

Base Type

G13

Nominal Length

4 ft

Bulb Shape

Endcap Material

Plastic

Enclosure Material

Glass

Lens Finish

Frosted

Compliance

Listings

UL Listed, UL Classified

Environment

Suitable for use in dry and damp environments

Fixture Rating

Suitable for use in enclosed fixtures

Certification Model Number

T10370(T8-12-48G-8CCT-HYB)

T20 Compliant

California Title 24 JA8 Compliant

California Energy Commission (CEC) Status

Lawful for Sales in California

NSF Listed

Meets NSF/ANSI standards for use in Food Zone (non-contact), Splash, and Non-Food Zones. Tube guard required in open fixtures.

RoHS

Mercury and UV free. RoHS-compliant components.

FCC

Complies with Part 15 of the FCC Rules

DLC Listed

This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: S-0GTH45

Other

Compatible Products

See Dimmer and Ballast compatibility lists

Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.

Note

All values are typical (tolerance +/- 10%)

Buy American Act Compliance

RAB values USA manufacturing! Upon request, RAB may be able to manufacture this product to be compliant with the Buy American Act (BAA). Please contact customer service to request a quote for the product to be made BAA compliant.
