W34-30L-840/MVS
W34-30L-840/MVS large main
  • Economy-grade wall pack with traditional look
  • Covers footprint of small HID wall packs
  • Available in various lumen packages
  • Integrated 0-10V dimming
  • 50,000-Hour LED lifespan
 View Technical Specs
View Price & Availability
Performance
Watts 30W
Color Temp 4000K (Neutral)
Lumens 3,497 lm
Efficacy 120.2 lm/W
Color Accuracy 83 CRI
L70 Lifespan 50,000 Hours
Type Constant Current
120V 0.25A
208V 0.15A
240V 0.13A
277V 0.12A
Input Watts 29.1W
Dimensions
Link to Dimension Drawing

Weight: 6.8 lbs

Technical Specifications
Electrical
Driver
Constant Current, Class 2, 120-277V, 50/60Hz, 120V: 0.25A, 208V: 0.15A, 240V: 0.13A, 277V: 0.12A
THD
3.46% at 120V, 4.25% at 277V
Power Factor
99.6% at 120V, 92.6% at 277V
Compliance
DLC Listed
This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: PPXBTG89
