WFRD6R139FA120WS

5 color temperatures in 1 SKU (2700K, 3000K, 3500K, 4000K, 5000K)

Back-lit deep regress remote driver downlight

No recessed housing or j-box required

Dimmable down to 5% on compatible dimmers, see Dimmer Compatibility List

IC and airtight rated

Suitable for indoor and outdoor use in dry, damp, and wet environments

View Technical Specs

View Price & Availability

Performance

Watts	13W
Color Temp	Field Adjustable
Lumens	1,128 lm
Efficacy	76.92307692
Color Accuracy	90 CRI
L70 Lifespan	50,000 Hours

Type	Constant Current
120V
208V
240V
277V
Input Watts	13W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 1.1 lbs

Technical Specifications

Performance

Product Type

Recessed Direct Mount

Lumens

1,000lm

Efficacy

76.9lm/W

Lifespan

50,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations

Wattage Equivalency

Equivalent to 75W Incandescent

LED Characteristics

LEDs

Back-lit LED array provides a uniform source with high efficiency and no pixilation

Color Accuracy (CRI)

90 CRI

Color Temperature

Field Adjustable dip switch 2700K/3000K/3500K/4000K/5000K

Electrical

THD

<25%

Power Factor

≥0.9

Dimmable

TRIAC and ELV (at 120V only).

Input Voltage

120V

Operating Frequency

60Hz

Operating Temperature

-30°C - 40°C

Other

Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.

Buy American Act Compliance

RAB values USA manufacturing! Upon request, RAB may be able to manufacture this product to be compliant with the Buy American Act (BAA). Please contact customer service to request a quote for the product to be made BAA compliant.

Construction

Size

Shape

Round

Finish

White

Trim Style

Smooth Trim

Lens

Regressed lens
Impact-resistant polycarbonate
Convex form and lamp-like apperance
Diffuse for even illumination

Air Tight

Housing certified Air Tight as per ASTM E283
