• High efficiency. Low price.
  • Ideal for industrial warehouse spaces
  • 100,000 hour LED lifespan
  • 5-Year, limited warranty
View Technical Specs
Performance
Watts 360W
Color Temp 4000K (Neutral)
Lumens 52,900 lm
Efficacy 141.6
Color Accuracy 84 CRI
L70 Lifespan 100,000 Hours
Type Constant Current
120V 3.00A
208V 1.73A
240V 1.48A
277V 1.34A
Input Watts 373.6W
Dimensions
Link to Dimension Drawing

Weight: 23.6 lbs

Technical Specifications

Installed with Lightcloud

Lightcloud is a commercial wireless lighting control system fully developed and supported by RAB. It's powerful and flexible, yet easy to use and install.

Learn More
Compliance
UL Listed
Suitable for damp locations
IESNA LM-79 & LM-80 Testing
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
DLC Listed
This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: P8UXTIDP
Performance
Lifespan
100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations
LED Characteristics
LEDs
Multi-chip, high-output, long-life LEDs
Color Uniformity
RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.
Construction
Operating Temperature
-20°C (-4°F) to 50°C (122°F)
Housing
22 gauge die formed with white powder coat finish. Y Hooks included for easy chain or cable mounting.
Reflector
White painted, reflective, die formed painted steel
Lens
Polycarbonate lens
Finish
Our environmentally friendly polyester powder coatings are formulated for high-durability and long-lasting color
Green Technology
Mercury and UV free. RoHS-compliant components.
Installation
Mounting
V hooks and optional pendant mounting. AEROBAY® comes with two 42" chains.
Lightcloud
Lightcloud Controller Installed
Integrated/embedded networked lighting control, luminaire-level lighting control. Fixture, Zone, and plug-load control from one powerful device. LLLC - capable of switching, 0-10Vdimming, power/energy monitoring. Can also be used to extend the range of the Lightcloud mesh network communication protocols. Offers the capability to set the maximum light output to a less-than-maximum state of an individual luminaire at the time of installation or commissioning. The High-End trim functionality is field reconfigurable via the Lightcloud mesh network communication protocols. The Lightcloud controller can be attached to the fixture, junction box, or electrical panel.
DLC system - N1XMLOEATBA
Learn more at www.lightcloud.com
Electrical
Driver
Class 2, Constant Current, 120-277V, 50/60 Hz, 120V: 3.00A, 208V: 1.73A, 240V: 1.48A, 277V: 1.34A
THD
3.39% at 120V, 6.4% at 277V
Power Factor
99.9% at 120V, 94.5% at 277V
Surge Protection
2.5kV
For areas prone to surges, upgrade to 10kV surge protection available
\
Other
Replacement
Replaces 1000W MH
5 Yr Limited Warranty
The RAB 5-year, limited warranty covers light output, driver performance and paint finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
