HALVS10L940-MG-A/LC

Spec Sheet Instructions Master Specification Features Spec Sheet

HALVS10L940-MG-A/LC

View Technical Specs

Performance

Watts	14W
Color Temp	4000K (Neutral)
Lumens	243 lm
Efficacy	17.4 lm/W
Color Accuracy	93 CRI
L70 Lifespan	50,000 Hours

Type	Constant Current
120V	0.12A
208V	0.07A
240V	0.06A
277V	0.06A
Input Watts	14W

Dimensions

Weight: 4.5 lbs

Technical Specifications

Installed with Lightcloud

Lightcloud is a commercial wireless lighting control system fully developed and supported by RAB. It's powerful and flexible, yet easy to use and install.

Learn More

Lightcloud

Lightcloud Controller Installed

LCLC/K
Fixture, Zone, and plug-load control from one powerful device. Capable of switching, 0-10V dimming, power monitoring. Can also be used to extend the range of the Lightcloud mesh network. Attach to fixture, junction box, or electrical panel. Learn more about Lightcloud.

Compliance

UL Listed

Suitable for damp locations. Recommended for indoor use only.

ADA Compliant

Meets ADA Requirements for wall-mounted luminaires.

IESNA LM-79 & LM-80 Testing

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

Performance

Lifespan

50,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations

Wattage Equivalency

Equivalent to 60W Incandescent

LED Characteristics

LEDs

Long-life, high-efficacy, surface-mount LEDs; binned and mixed for uniform light output and color

Color Stability

LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period

Color Uniformity

RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

Electrical

Driver

Constant Current, Class 2, 120-277VAC, 50/60Hz, 350mA or 640mA

Dimming Driver

0 - 10V (at 120-277V), TRIAC and ELV (at 120V only)

THD

19.8% at 120V, 21.6% at 277V

Power Factor

96.4% at 120V, 85.7% at 277V

Battery Backup Light Loss Factor

0.33

Construction

Housing

Die-cast and extruded aluminum

Mounting

Wall mount with junction box included

Lens

Acrylic lens with metallic spun gold print. See installation sheet for cleaning instructions.

Operating Temperature

-20°C (-4°F) to 40°C (104°F)

Green Technology

Mercury and UV free. RoHS-compliant components.

Finish

Luxuriously Electroplated Antique Bronze

Other

Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.

Buy American Act Compliance

RAB values USA manufacturing! Upon request, RAB may be able to manufacture this product to be compliant with the Buy American Act (BAA). Please contact customer service to request a quote for the product to be made BAA compliant.
