WP3XFU150
Performance
| Watts | 150/130/100W |
| Color Temp | 3000/4000/5000K |
| Lumens | 13,254-21,552 lm |
| Efficacy | 132.5-151.1 lm/W |
| Color Accuracy | 81-84 CRI |
| L70 Lifespan | 100,000 Hours |
| Type | Constant Current |
| 120V | 1.19A/1.04A/0.80A |
| 208V | 0.69A/0.60A/0.46A |
| 240V | 0.63A/0.55A/0.42A |
| 277V | 0.55A/0.47A/0.36A |
| Input Watts | 94.6-148.3W |
Dimensions
Weight: 11.5 lbs
Technical Specifications
Field Adjustability
Field Adjustable
Field Adjustable Light Output:
150W/130W/100W (factory default 150W)
Color temperature (selectable by 3000K, 4000K and 5000K)
150W/130W/100W (factory default 150W)
Color temperature (selectable by 3000K, 4000K and 5000K)
Compliance
UL Listed
Suitable for wet locations
IESNA LM-79 & LM-80 Testing
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
IP Rating
Ingress protection rating of IP65 for dust and water
Performance
Lifespan
100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations
Wattage Equivalency
150W: 750W Metal Halide
130W: 400W Metal Halide
100W: 400W Metal Halide
130W: 400W Metal Halide
100W: 400W Metal Halide
LED Characteristics
LEDs
Long-life, high-efficiency, surface-mount LEDs
Electrical
Driver
150W: Constant Current, Class 1, 120-277V, 50/60 Hz, 120V: 1.19A, 208V: 0.69A, 240V: 0.63A, 277V: 0.55A
130W: Constant Current, Class 1, 120-277V, 50/60 Hz, 120V: 1.04A, 208V: 0.60A, 240V: 0.55A, 277V: 0.47A
100W: Constant Current, Class 1, 120-277V, 50/60 Hz, 120V: 0.80A, 208V: 0.46A, 240V: 0.42A, 277V: 0.36A
130W: Constant Current, Class 1, 120-277V, 50/60 Hz, 120V: 1.04A, 208V: 0.60A, 240V: 0.55A, 277V: 0.47A
100W: Constant Current, Class 1, 120-277V, 50/60 Hz, 120V: 0.80A, 208V: 0.46A, 240V: 0.42A, 277V: 0.36A
Dimming Driver
Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.
THD
5.56% at 120V, 8.93% at 277V
Power Factor
99% at 120V, 94% at 277V
Photocell
120-277V selectable photocell that can be turned on and off.
Surge Protection
L-N: 6kV, L&N-E:6kV
Construction
Cold Weather Starting
The minimum starting temperature is -40°C (-40°F)
Ambient Temperature
Max Power Temp Rating: 50°C (122°F)
Middle Power Temp Rating: 57°C (134°F)
Low Power Temp Rating: 63°C (146°F)
Middle Power Temp Rating: 57°C (134°F)
Low Power Temp Rating: 63°C (146°F)
Housing
Die-cast aluminum
Lens
Tempered glass
Finish
Formulated for high durability and long-lasting color
Green Technology
Mercury and UV free. RoHS-compliant components.
Installation
Mounting
Wall mount
Other
5 Yr Limited Warranty
The RAB 5-year, limited warranty covers light output, driver performance and paint finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
